Axicon 15500
The Axicon 15500 barcode verifier is designed to read both linear and twodimensional matrix barcodes simultaneously. All the symbols seen in its field of view are verified individually, and the user simply selects each barcode in turn to see the specific results.
| Model | Axicon 15500 |
| Doğrulanan Semboller | EAN-8, EAN-13, UPC-A, UPC-E, ITF-14, GS1-128, GS1 DataMatrix, GS1 QR Code, Data Matrix, GS1 Databar, QR Code, Code 39, Code 93, Code 128, Codabar, ITF, MSI Plessey, Laetus Pharmacode, GS1 Databar Composite Code. |
|---|---|
| Uygulama Standartları | 03, 05, 06, 08, 10, 16 and 20. The software automatically identifies the symbology and its nominal bar width (x-dimension) and adjusts the aperture size to comply with the symbology specifications and relevant ISO/IEC standard. |
| Analiz | Full ISO/IEC 15416 parameter analysis, average bar gain, check digit validation, data length, nominal bar width (x-dimension), symbol structure, quiet zone validation, wide to narrow ratio. Full ISO/IEC 15415 parameter analysis (parameters vary according to the symbology). Nominal bar width (x-dimension), average module gain. Data content checker for Application Identifiers with GS1-128, GS1 DataBar, GS1 DataMatrix and GS1 QR Codes. |
| Boyutlar | 205 x 195 x 141 mm (8”x 7.6” x 5.5”) - Maximum image size 60mm x 45mm (2.36” x 1.77”) |
| Ağırlık | 1.28 Kg |
| Yapı | APlastic housing, CMOS sensor, LED illumination |
| Arabirim | USB 2.0 |
